DMCC 4. Products DMCC Software

Converter SDU, Equipment Database, Automation Scripts

During years DMCC develops a number of specific software solutions (scripts), databases and software models. Initially, all these developments have been done for internal purposes to minimize the risk of wrong data, to increase the efficiency of system studies, and to improve model accuracy in PowerFactory software.

All together, they form DMCC knowledge base and unique know-how.

DMCC presents the following in house developed Software Products:

  • Database of busbar system topology in PowerFactory.
  • Database of low voltage equipment and protection relays.
  • Database on Electrical parameters of HV circuit breakers in PowerFactory.
  • Database on Electrical parameters of overhead lines based on the geometry of the towers in DIgSILENT PowerFactory.
  • Database on electrical parameters of power systems equipment in software DIgSILENT PowerFactory.
  • Database on Elements for contingency analysis (N-1) of overhead lines and shunt reactors of 750 kV of the IPS of Ukraine.
  • Database on Model of 110, 220 and 330 kV electrical networks of Crimea.
  • Database on Normative disturbances for stability study of the integrated power system of Ukraine.
  • Database on Parameters of an integrated model of electric networks of Dniprooblenergo.
  • Database on Parameters of an integrated model of electric networks 110/35/10/6 kV of the South-West area of Odessa region.
  • Database on Parameters of an integrated model of electric networks 110-150 kV of Kirovogradoblenergo.
  • Database on Parameters of an integrated model of electric networks of Zaporizhyaoblenergo.
  • Database on Parameters of an integrated model of electric networks of Chernigivoblenergo.
  • Database on Parameters of an integrated model of electric networks of Kyivenergo and Kyivoblenergo.
  • Database on Parameters of an integrated model of electric networks of Sumyoblenergo.
  • Database on Parameters of an integrated model of electric networks of Kharkivoblenergo.
  • Database on Parameters of an integrated model of electric networks of Khmelnytskoblenergo.
  • Database on parameters of AVRs and governor speed controls of generators of Ukrainian power plants.
  • Database on Parameters of model of integrated power system of Ukraine for load flow and steady state stability analysis.
  • Database on Parameters of model of integrated power system of Ukraine for harmonic modes calculation.
  • Database on Parameters of models of UELs at power stations of Ukraine.
  • Database on Parameters of perspective models (2017/2027) of integrated power system of Ukraine for load flow and steady state stability analysis.
  • Database on Voltage Dependency of Load Centres of IPS of Ukraine in PowerFactory.
  • Software for automated calculations of network admissible states taking into account N-1 and N-2 simulations.
  • Software for Automated search of errors in the models of schemes and modes of electric systems.
  • Software for Automated transient stability calculations in the integrated power system of Ukraine.
  • Software for Calculation of single phase pair of autotransformer 750 kV and regulated transformer - ComRat.
  • Software for Computation of critical clearing time of fault according to the criteria of transient stability.
  • Software for Computation of energy losses in distribution networks of 6-10/0,4 kV.
  • Software for Converting of data from SDU to PowerFactory DGS files formats.
  • Software for Creating models of electric network in PowerFactory format based on EXCEL data in a format SLAMO.
  • Software for Creating models of frequency of emergency protection of the IPS of Ukraine.
  • Software for Modeling, estimation of efficiency and setting emergency automation APNU and AROL of electrical systems interface with distributed PV plants.
  • Software for Monitoring and adjustment of reserves for reactive power in the models of prospective modes of power systems.
  • Software for On-line computation of critical states of power systems according to the criteria of static aperiodic stability.
  • Software for Relay protection settings of electrical systems analysis – Protection SCAN.
  • Software for Simulation of auxiliary systems of nuclear power plants.
  • Software for Simulation of frequency protection automatics of nuclear units.
  • Software for Simulation of quadratic regulation transformers in autotransformers of 750/330 kV.
  • Software for Simulation of the frequency and active power control system in the integrated power system of Ukraine.
  • Software for Simulation of the frequency and active power control system (system, station, unit control levels) in the integrated power system of Ukraine.
  • Software for Stochastic simulation of load ramp of nuclear power units auxiliary loads.
  • Software for UFLS relays setting updates and tuning.
  • Software for Visualisation of impedance trajectories during out of step (asynchronous) operation.
  • Software for Voltage stability analysis and calculation of critical voltage in electrical systems by the QV-curves method.
  • Software Model for Simulation of UFLS relays and automatic frequency recovery re-closer.
  • Software Model of turbo-generators excitation system and AVR - type SVTH 2,0k / 300-C2T2- AR24-UHL4 for turbo-generator unit №2 Kharkiv CHPP-5 in DIgSILENT PowerFactory.
  • Software Model of UFLS relay with RoCoF principle.
  • Software Model turbo-generators excitation system and automatic excitation control - type SVTH 3,85k / 375-1KS2T2,5- AR24-UHL4 for turbo-generator unit №3 Kharkiv CHPP-5 in DIgSILENT PowerFactory.
  • Software for automation of oscillatory stability calculations in IPS of Ukraine.
  • DataBase of settings for simulation and tuning of Special Protection Automatics AOZN type.Software for automation of electricity losses’ calculations in the transmission grid of IPS of Ukraine (2020)
  • Software for automatic identification of electrical oscillation centers in asynchronous modes of power systems (2020)
  • Database of parameters of the model of the IPS of Ukraine with HVDC systems (2021)
  • Software for advanced automated search of errors in the models of electrical networks (2021)



  • All IP rights are preserved DMCC 2003-2021.
